Power Harness Kit

1. Park the machine on a level surface.

2. Engage the parking brake.

3. Lower the cutting units.

4. Shut off the engine and remove the key.

Unlatch and open the hood (Figure 1).

Figure 1

1. Remove the negative battery cable from the battery post (Figure 2).



   Figure 2

   1. Negative battery cable
   2. Positive battery cable

2. Lift the insulator and remove the positive battery cable from the battery post (Figure 2).

Parts needed for this procedure:

1. Insert the maxifuse (60 A) into the large 2-slot fuse holder of the power harness (Figure 3).



   Figure 3

   1. Maxifuse (60 A)
   2. Solenoid
   3. 4-slot connector (power harness)
   4. Cover (small fuse holder)
   5. Fuse (10 A)
   6. Small fuse holder (power harness)
   7. 2-slot fuse holder (power harness)

2. Remove the cover from the small fuse holder (Figure 3).

3. Insert the fuse (10 A) into the small fuse holder and install the cover (Figure 3).

4. Insert the solenoid into the 4-slot connector (Figure 3).

Parts needed for this procedure:

1. At the right side of the machine and above the battery, route the power harness along the inboard side of the upper tube of the engine-support frame (Figure 4 and Figure 5).



   Figure 4

   1. Power harness
   2. Upper tube (engine-support frame)


   Figure 5

   1. Power harness
   2. Outward, right side of the machine

2. Route the power harness upward along the cross tube (Figure 6 and Figure 6).



   Figure 6

   1. Cross tube
   2. Ring terminals
   3. Power harness


   Figure 7

   1. Front of the machine
   2. Power harness
   3. Outward, right side of the machine

3. Route the ring terminals of the power harness to the clamps of the battery cables (Figure 6).

4. Route the power harness branch with the 2-pin connector, single-pin connector, and 8-socket connector upward along the front of the cross tube and secure it with 2 cable ties (Figure 7).



   Figure 8

   1. 2-pin connector, single-pin connector, and 8-socket connector
   2. Cable ties
   3. Cross tube

Parts needed for this procedure:

1. Bundle the bullet terminal with the white wire and the 2-socket connector with the black wire and the blue wire of the power harness (Figure 9).



   Figure 9

   1. Cable ties
   2. 2-socket connector (black wire and blue wire—power harness)
   3. Bullet terminal (white wire—power harness)
   4. Single pin connector (white wire—power harness)

2. Bundle the single pin connector with the white wire of the power harness (Figure 9).

3. Secure the wire bundles to the machine wire harness with cable ties (Figure 9).

1. Connect the positive cable to the battery and tighten the battery-clamp nut (Figure 13).



   Figure 13

   1. Positive battery cable
   2. Negative battery cable

2. Connect the negative cable to the battery and tighten the battery-clamp nut (Figure 13).

3. Assemble the insulator over the positive battery terminal (Figure 13).

Close and latch the hood.

Figure 14
